Deploy Resoto to AWS with Cloud Development Kit

We provide a CDK construct to simplify the deployment of Resoto to AWS.

tip

The Resoto web installer is the easiest way to get a production-grade setup, whereas the CDK construct is a bit more involved but gives you more control over the setup and does not require you to send us your cloud credentials.

Prerequisites

• Git
• AWS account with IAM role permissions
• AWS command-line interface
• kubectl command-line tool
• Node.js

Directions

1. Run the following commands in the terminal:

   $ git clone git@github.com:someengineering/resoto-cdk.git
   $ cd resoto-cdk
   $ npm ci

2. Then, deploy Resoto with the following command:

   $ npm run cdk deploy -- --parameters ResotoTag=edge
   note

   If this is your first CDK deployment, you will need to bootstrap your AWS account. You can do so with the following command:

   $ npm run cdk bootstrap
   info

   It is possible to override the default CloudFormation parameter values:

   $ npm run cdk deploy -- --parameters ResotoTag=edge --parameters MngInstanceType=r5a.xlarge

   Parameter	Description	Default Value
   ResotoTag	The Resoto image tag to use	3.6.5
   MngMaxSize	The maximum number of instances in the k8s managed node group	3
   MngMinSize	The minimum number of instances in the k8s managed node group	1
   MngDesiredSize	The desired number of instances in the k8s managed node group	1
   MngInstanceType	The instance type of the k8s managed node group	r5a.xlarge

3. Confirm the deployment. This will trigger CDK to create an EKS cluster and install the Resoto Helm chart.

   info

   The deployment will take approximately 30 minutes. You can follow the progress in the terminal.

   Once deployment is complete, you will see output similar to the following:

   Outputs:
   ResotoEKS.ResotoEKSConfigCommandXXXX = aws eks update-kubeconfig ...
   ResotoEKS.ResotoPskSecret = kubectl get secrets ...
   ResotoEKS.ResotoUI = https://a3xxxxxx.us-east-1.elb.amazonaws.com:8900

   Stack ARN:
   arn:aws:cloudformation:us-east-1:115717706081:stack/ResotoEKS/e1b9e6a0-d5f6-11eb-8498-0a374cd00e27e
   info

   • The value of ResotoEKS.ResotoEKSConfigCommandXXXX in Outputs is a command to configure kubectl to connect to the EKS cluster.

     You can check that the connection is working by running the following command:

     $ kubectl get pods -A | grep resotocore
     ​resoto  resoto-resotocore-xxx  1/1  Running   0  32m

   • The value of ResotoEKS.ResotoPskSecret in Outputs is a command to retrieve the Resoto PSK.

     $ kubectl get secrets resoto-psk -o jsonpath='{.data.psk}' | base64 -d

   • The value of ResotoEKS.ResotoUI in Outputs is the URL of the Resoto UI.
