How to Clean Up AWS VPC Resources

When deleting AWS VPCs, dependent network resources are sometimes left behind.

Fix Inventory's cleanup_aws_vpcs plugin can find and delete these orphaned resources, which include:

  • AWS VPC Peering Connections
  • AWS EC2 Network ACLs
  • AWS EC2 Network Interfaces
  • AWS ELB
  • AWS ALB
  • AWS ALB Target Groups
  • AWS EC2 Subnets
  • AWS EC2 Security Groups
  • AWS EC2 Internet Gateways
  • AWS EC2 NAT Gateways
  • AWS EC2 Route Tables

Prerequisites​

This guide assumes that you have already installed and configured Fix Inventory to collect your AWS resources.

Directions​

  1. Execute the following command in Fix Inventory Shell to open the Fix Inventory Worker configuration for editing:

    > config edit fix.worker

  2. Enable cleanup by modifying the fixworker section of the configuration as follows:

    fixworker:
      # Enable cleanup of resources
      cleanup: true
      # Do not actually cleanup resources, just create log messages
      cleanup_dry_run: false
      # How many cleanup threads to run in parallel
      cleanup_pool_size: 16

    When cleanup is enabled, marked resources will be deleted as a part of the collect_and_cleanup workflow, which runs each hour by default.

    tip

    Set cleanup_dry_run to true to simulate cleanup without actually deleting resources.

  3. Update the plugin_cleanup_aws_vpcs section with the desired target cloud account IDs and setting the enabled property to true:

    cleanup_aws_vpcs plugin configuration
    plugin_cleanup_aws_vpcs:
      # Dictionary of key cloud with list of account IDs for which the plugin should be active as value
      config:
        aws:
          - '1234567'
          - '567890'
      # Enable plugin?
      enabled: true

The plugin will now run each time Fix Inventory emits the post_cleanup_plan event. The post_cleanup_plan event is emitted in the cleanup phase of the collect_and_cleanup workflow.

Each time the cleanup_aws_vpcs plugin runs, network resources associated with VPCs that have been deleted or marked for cleanup will also be flagged for removal during the next cleanup run.
