Resoto Core Configuration
Network Interfaces​
For security reasons, Resoto Core only listens on the loopback interface by default. This can be changed via the resotocore.api.web_hosts option in the resoto.core configuration.
Execute the following command in Resoto Shell to open the relevant configuration for editing:
> config edit resoto.core
resotocore:
...
# API related properties.
api:
...
# TCP host(s) to bind on (default: ['localhost'])
web_hosts:
- '::'
- '0.0.0.0'
# TCP port to bind on (default: 8900)
web_port: 8900
...
Alternatively, you can use the config set command:
> config set resoto.core resotocore.api.web_hosts=["::", "0.0.0.0"]
TLS Certificate​
Resoto attempts to find all local IP addresses and hostnames and add them to the subject alternative names (SAN) list of the x509 certificate. If your system has additional DNS names, you can add them to the SAN list via the resotocore.api.host_certificate.san_dns_names option in the resoto.core configuration.
Execute the following command in Resoto Shell to open the relevant configuration for editing:
> config edit resoto.core
resotocore:
...
# API related properties.
api:
...
# The certificate configuration for this server.
host_certificate:
# The common name of the certificate
common_name: 'some.engineering'
# Include loopback in certificate
include_loopback: true
# List of DNS names to include in CSR
san_dns_names:
- 'some.engineering'
- 'resoto.some.engineering'
- '*.some.engineering'
# List of IP addresses to include in CSR
san_ip_addresses: []
...
Workflow Schedules​
By default, the collect_and_cleanup workflow runs at the start of each hour. This setting can be configured using standard cron syntax.
Execute the following command in Resoto Shell to open the relevant configuration for editing:
> config edit resoto.core
resotocore:
...
# Workflow related properties.
workflows:
...
collect_and_cleanup:
# Cron expression as schedule for the workflow to run.
schedule: '0 * * * *'
...
Alternatively, you can use the config set command:
> config set resoto.core resotocore.workflows.collect_and_cleanup.schedule="0,30 * * * *"
Snapshot Schedules​
Resoto Rewind allows you to set up automated snapshots. You can specify the number of snapshots to retain per label and the associated schedule.
Execute the following command in Resoto Shell to open the relevant configuration for editing:
> config edit resoto.core.snapshots
Here's an example of a snapshot schedule configuration:
snapshots:
hourly:
retain: 24
schedule: 0 * * * *
daily:
retain: 7
schedule: 0 0 * * *
weekly:
retain: 4
schedule: 0 0 * * 0
monthly:
retain: 12
schedule: 0 0 1 * *
yearly:
retain: 10
schedule: 0 0 1 1 *
These labels (hourly, daily, etc.) are user-definable, allowing for a wide range of snapshot schedules. The schedule is a crontab syntax. The above values are the defaults, resulting in a total of 57 snapshots. Depending on your available storage you can increase or decrease the number of snapshots retained.
