Get the currently defined model.

GET

/graph/:graph_id/model

Get the currently defined model.

Request

Path Parameters

    graph_id stringrequired

    The identifier of the graph

    Example: resoto

Query Parameters

    flat boolean

    If true, the hierarchy of complex kinds is flattened, holding all properties and all merged metadata.

Responses

The list of all kinds.

Schema
  • Array [
  • oneOf
    min_length string

    The minimal length of this string

    max_length string

    The maximal length of this string

    pattern string

    The regexp pattern, that this string has to adhere to

    enum string[]

    The allowed values of this string enumerated here

    runtime_kind string

    Possible values: [string, int32, int64, float, double, boolean, date, datetime]

    The runtime kind of this kind

    any
    fqn string

    The fully qualified name of the kind

  • ]
