Resoto Core
Resoto Core (resotocore
) is the graph persistence and search backend of Resoto. It maintains the graph of resources and provides APIs to update and access them.
Within Resoto Core, there are workflows consisting of steps that result in actions like collect
, cleanup
or generate_metrics
. These actions are received by components like Resoto Worker and Resoto Metrics.
somecr.io/someengineering/resotocore:3.8.0
API​
The Resoto Core API is exposed at https://<resoto-address>:8900/api-doc
. You can also access it at https://resoto.com/docs/reference/api
.
Resoto Core has two API endpoints to connect to for CLI purposes:
The /cli/evaluate
functinality is used internally on every /cli/execute
before the command executes.
Below is a simulation of sending a Resoto Shell search to the API.
We will evaluate the search before executing it for demonstration. We also introduce a search with a typo to show the response if not successful.
Evaluate​
> echo 'search is("resource") limit 1' | http :8900/cli/evaluate
​HTTP/1.1 200 OK
​Content-Length: 47
​Content-Type: application/json; charset=utf-8
​Date: Wed, 06 Oct 2021 15:13:08 GMT
​Server: Python/3.9 aiohttp/3.7.4.post0
​[
​ {
​ "execute_query": "is(\"resource\") limit 1"
​ }
​]
> echo 'graph=resoto search is("resource") limit1' | http :8900/cli/evaluate
​HTTP/1.1 400 Bad Request
​Content-Length: 151
​Content-Type: text/plain; charset=utf-8
​Date: Wed, 06 Oct 2021 15:13:33 GMT
​Server: Python/3.9 aiohttp/3.7.4.post0
​Error: ParseError
​Message: expected one of '!=', '!~', '<', '<=', '=', '==', '=~', '>', '>=', '[A-Za-z][A-Za-z0-9_]*', '`', 'in', 'not in', '~' at 0:21
Execute​
> echo 'graph=resoto search is("resource") limit 1' | http :8900/cli/execute
​HTTP/1.1 200 OK
​Content-Type: application/json
​Date: Wed, 06 Oct 2021 15:08:10 GMT
​Server: Python/3.9 aiohttp/3.7.4.post0
​Transfer-Encoding: chunked
​[
​ {
​ "id": "06ee67f7c54124c019b80a7f53fa59b231b374fe61f94b91e0c26729440d095c",
​ "kinds": [
​ "base_cloud",
​ "cloud",
​ "resource"
​ ],
​ "metadata": {
​ "python_type": "resoto.baseresources.Cloud"
​ },
​ "reported": {
​ "ctime": "2021-09-25T23:49:38Z",
​ "id": "gcp",
​ "kind": "cloud",
​ "name": "gcp",
​ "tags": {}
​ },
​ "revision": "_d_7eKMa---",
​ "type": "node"
​ }
​]
> echo 'graph=resoto search is("resource") limit1' | http :8900/cli/execute
​HTTP/1.1 400 Bad Request
​Content-Length: 151
​Content-Type: text/plain; charset=utf-8
​Date: Wed, 06 Oct 2021 15:26:54 GMT
​Server: Python/3.9 aiohttp/3.7.4.post0
​Error: ParseError
​Message: expected one of '!=', '!~', '<', '<=', '=', '==', '=~', '>', '>=', '[A-Za-z][A-Za-z0-9_]*', '`', 'in', 'not in', '~' at 0:21
More API Endpoints
Resoto Core is the central hub for everything Resoto does. You can explore additional API endpoints at https://<resoto-address>:8900/api-doc
or https://resoto.com/docs/reference/api
.
